FiiO FX25 Tribrid IEMs
Seven-driver hybrid IEMs
The FiiO FX25 combines one dynamic driver, two Knowles balanced armature drivers, and four Sonion electrostatic drivers in each earpiece. Dedicated drivers cover different parts of the frequency range, while acoustic chambers and a second-order RLC filter help control their output. Lightweight carbon fiber shells house the seven-driver array, and a detachable silver-plated monocrystalline copper cable includes interchangeable 3.5mm, 4.4mm, and USB-C DAC plugs.
Seven drivers with dedicated roles
Each earpiece divides reproduction among three driver technologies. A dynamic driver handles bass, two custom Knowles balanced armatures cover the midrange and its transition into the treble, and four Sonion electrostatic drivers reproduce high and ultra-high frequencies. This division lets FiiO tune each driver group for its assigned range and blend their output into a balanced presentation.
Four electrostatic drivers for upper-frequency detail
The FX25 uses Sonion EST65QB02 electrostatic drivers, also featured in FiiO’s flagship FX17. These drivers extend up to 50kHz, supporting the reproduction of upper-frequency harmonics and the sense of air around voices and instruments. The complete earphone has a specified frequency response of 10Hz–40kHz.
Custom balanced armatures for vocal body and clarity
Two independent Knowles balanced armature drivers serve different acoustic roles. One handles the upper midrange and treble transition, helping connect the vocal range with the electrostatic drivers. The other uses a vented rear chamber to increase airflow and diaphragm excursion, adding fullness to the lower midrange for a richer vocal presentation.
A lightweight alloy diaphragm for bass
The 0.39-inch (10mm) dynamic driver pairs a lithium–magnesium alloy diaphragm with a flexible polyurethane surround. The diaphragm’s low density and rigidity help keep moving mass low while controlling unwanted flexing. The surround supports diaphragm movement, helping reduce breakup and preserve the texture of voices and instruments.
A dedicated filter for smoother treble
A second-order RLC band-stop filter targets resonant peaks associated with the drivers and acoustic chambers. By attenuating these narrow frequency regions, the circuit helps smooth the treble response and reduce sharpness. It works alongside the driver arrangement and acoustic tuning to support comfortable listening over longer sessions.
An acoustic path shapes the bass
FiiO’s patented S.Turbo structure uses a turbine-shaped sound tube in the front chamber to strengthen bass energy and impact. The acoustic path also filters unwanted midrange and treble output from the dynamic driver, helping its bass output blend with the balanced armature drivers.
A vented rear chamber for pressure balance
A small rear-chamber vent uses air damping to balance pressure across the dynamic driver’s front and rear chambers. FiiO tunes this structure to improve bass extension and reduce the masking of midrange vocals by other frequencies, helping voices remain clear within the mix.
Carbon fiber shells with low weight
Each earpiece weighs approximately 0.25 ounces (7g), excluding the cable. The shells use multiple layers of carbon fiber bonded and shaped to form the compact, curved housings. Carbon fiber combines low density with rigidity, providing resistance to pressure and deformation while keeping weight down. Its naturally varying weave gives each pair a slightly different appearance.
A silver-plated copper cable with cryogenic treatment
The included cable uses 6N monocrystalline copper conductors with silver plating. FiiO treats the cable with liquid nitrogen at −313.6°F (−192°C) for more than 100 hours, a process intended to release internal stress in the metal. The approximately 3.9-foot (1.2m) cable detaches through standard 0.78mm 2-pin connectors, allowing you to replace it with compatible alternatives.
Three plugs for different sources
Interchangeable 3.5mm single-ended, 4.4mm balanced, and USB-C DAC plugs let you use the included cable across several source types. Connect to a headphone amplifier or portable player through an analog output, or use the DAC plug with a compatible USB-C device. A twist-lock mechanism secures the interchangeable plugs.
Ear tips and storage included
The FX25 includes 22 pairs of ear tips, with foam, silicone, double-flange, SpinFit, HS18, and HS20 liquid silicone options. Different shapes and materials let you adjust the seal and fit. An included NEST CUBE case combines aluminum alloy with PU leather for storage between listening sessions.
Product highlights
- Seven drivers per earpiece: one dynamic, two balanced armature, and four electrostatic
- Custom Knowles balanced armature drivers
- Four Sonion EST65QB02 electrostatic drivers per side
- Lithium–magnesium alloy diaphragm dynamic driver
- Second-order RLC band-stop filter circuit
- Patented S.Turbo acoustic structure
- Vented rear chamber for pressure balancing
- Lightweight carbon fiber shells
- Cryogenically treated 6N silver-plated monocrystalline copper cable
- Detachable 0.78mm 2-pin connections
- Interchangeable 3.5mm, 4.4mm, and USB-C DAC plugs
- 22 pairs of ear tips and NEST CUBE storage case
- Hi-Res Audio certification
Specs
- Type: Dynamic, balanced armature, and electrostatic hybrid in-ear monitors
- Wearing style: In-ear with over-ear cable routing
- Drivers per earpiece: One dynamic driver, two balanced armature drivers, and four electrostatic drivers
- Dynamic driver: 0.39-inch (10mm) lithium–magnesium alloy diaphragm
- Balanced armature drivers: One custom Knowles midrange driver and one custom Knowles treble driver
- Electrostatic drivers: Four Sonion drivers
- Frequency response: 10Hz–40kHz
- Impedance: 20Ω at 1kHz
- Sensitivity: 106dB/mW at 1kHz
- Shell material: Carbon fiber
- Weight per earpiece: Approximately 0.25 ounces (7g), excluding cable
- Cable: Liquid-nitrogen-treated silver-plated monocrystalline copper
- Cable length: Approximately 3.9 feet (1.2m)
- Earphone connectors: 0.78mm 2-pin
- Plug mechanism: Straight interchangeable plugs with twist-lock connection
- Included plug types: 3.5mm single-ended, 4.4mm balanced, and USB-C DAC
- Color: Twilight Mountain Brown
What’s included
- FiiO FX25 earphones, one pair
- Detachable cryogenically treated silver-plated monocrystalline copper cable
- 3.5mm interchangeable plug
- 4.4mm interchangeable plug, preinstalled
- USB-C DAC tuning plug
- Foam ear tips, two pairs in medium
- Bass ear tips, three pairs in small, medium, and large
- SpinFit ear tips, three pairs in small, medium, and large, with medium preinstalled
- Vocal ear tips, three pairs in small, medium, and large
- Double-flange ear tips, two pairs in medium
- Balanced ear tips, three pairs in small, medium, and large
- HS18 ear tips, three pairs in small, medium, and large
- HS20 liquid silicone ear tips, three pairs in small, medium, and large
- NEST CUBE storage case
- Magnetic cable clip
- Cleaning brush
- Quick start guide
- FX25 packaging box
